62 Installing a Multi-Module Library
8 On the top of the X-axis chain assembly, lock down the Y-axis home sensor cable by pressing down on
the hold-down.
9 Test the Y-axis assembly by moving the accessor assembly to its home position and verifying the cables
do not have contact with the cables routed up the bulkhead. If they do, reposition the cables along the
bulkhead with the Velcro straps.
Y-axis home
sensor cable
hold down
