76 Installing a Multi-Module Library
2 Remove the nine (9) 2.5 mm screws that attach the right side panel to the module.
Note
Three screws are located at the front corner post, three at the back corner post,
and three at the storage wall.
2.5 mm screw
2.5 mm screw
2.5 mm screw
2.5 mm screws
front of module
2.5 mm screws
2.5 mm screws
back of module
