Radwin 2000+ SERIES - Figure 8-3 Downlink - P; Table 8-2 Performancem

RADWIN2000+SeriesUserManual Release4.2.40 8‐8
ObtainingReports
Figure8‐3:Downlink‐PerformanceMonitoringreport‐Validdata
Theon‐screenreportmaybescrolledverticallyandhorizontally.Themeaningofthecolumn
headingsisshowninthefollowingtable:
Table8‐2:PerformanceMonitoringFields
ColumnHeading
Abbreviation
Meaning
Description
Integrity Validdataflag
Greencheckmarkforcurrentandvalid;Redcr ossfor
invalidateddata(Seeexamplebelow).Notethatthe
PerformanceMonitoringdataisnotvalidifnotallthe
valueswerestored(e.g.,duetoclockchangeswithin
theint ervalorpowerupreset)
Date&Time Timestamp
Dataarerecordedevery15minutes;thelast30days
ofrecordingsaremaintained.Roll‐overisatmidnight.
UAS
Unavailable
Seconds
Secondsinwhichtheinterfacewasoutofservice.
ES Erroredseconds
Thenumberofsecondsinwhichtherewasatleast
oneerrorblock.
SES
SevereErrored
Seconds
Thenumberofsecondsinwhichtheservicequality
waslowasdeterminedbytheBBERthreshold.
BBE
Background
BlockError
Thenumberoferroredblocksinaninterval.
RxMBytes
Received
Mbytes
ThenumberofMegabytesreceivedatthespecified
portwithintheinterval
TxMBytes
Transmitted
Mbytes
ThenumberofMegabytestransmittedatthe
specifiedportwithintheinterval.
AboveTraffic
Thresh
Thresholdsetin
Figure 8‐2
Secondscountwhenactualtrafficexceededthe
threshold
ActiveSeconds
ThenumberofsecondsthattheconfiguredEthernet
serviceisactive
