UserPortConnectors
D.3UserPortConnectors
D.3.1LANPort
TheLAN10/100BaseTinterfaceterminatesinan8‐pinRJ‐45connector,wiredinaccordance
toTable D‐4.
D.4DCPowerTerminals
D.4.1DCPoE
TableD‐4:FastEthernetConnectorPinout
Function Signal Pin
TransmitData(positive) TD(+) 1
TransmitData(negative) TD(–) 2
ReceiveData(positive) RD(+) 3
ReceiveData(negative) RD(–) 6
TableD‐5:TerminalBlock2‐pin‐48VDC
Function Pin
+
Right
–
Left

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
