Radwin 2000+ SERIES User Manual

RADWIN2000+SeriesUserManual Release4.2.40 5‐15
Preferences:Monit or
5.8.1Preferences:Monitor
Figure5‐11:MonitorPreferences
File: PlaceacheckmarkheretosavetrafficandidentificationinformationtotheMonitor
file.ThecontentoftheMonitorfileisdescribedindetailin Chapter8,Monitoring
andDiagnostics.
Clicktheexplorerbuttontoselectthelocationofthisfile.
Clicktheselectheadersbuttontoselectthecategoriesofdatatobesaved
intheMonitorfile.
Fromthescreenthatappears,placeacheckmarknexttoeachcategoryofda ta
youwishtobesavedintheMonitorfile
1
.ClickOKtoacceptyourchoices.
Interval:SavethedataeveryXsecondstotheMonitorfile(andtheUtilizationfileifrelevant).
Xcanbeanintegervalueonly,andfrom1to60.Thisfilecanbeverylargevery
quickly,soifyouwanttostoredataforalengthyperiodoftime,choosealarge
number.
TheKMZbuttonisnotfunctionalhereandcanbeignored.
Rx/TxRateUnits:ChooseMegabitspersecond(Mbps),orFramespersecond(Fps)
ShowIP:DeterminewhichIPaddressformattoshowonthemainwindowforeachunit:IPv4
orIPv6.TheIPv6optionwillworkonlyifyouhavedefinedanIPv6addressforthe
unit.
IPv6AddressFormat:IfshowingIPv6addresses,chooseCompressedorExpanded.
1. Theremaybecategorieslistedthatarenotrelevantforthespecificradiomodelyouareworkingwith.Ignore
thosecategories.

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
