IDU‐H/HPaggregationunit
Figure4‐1:GbEPoEdevice
4.3.3IDU‐H/HPaggregationunit
TheIDU‐H/HPprovidesaggregationformultipleRADWINradiosatahubsite.Itsupportsall
RADWINradios.Itfeatures‐
• 6PoEports(PoElegacymode/RADWINPoE),upto35WperPoEport
• 2LANInterfaces10/100/1000Mbps;auto‐negotiation
• 2SFPportsof1000Mbps(standardMSA)
Itis19”rackmounted,1Uandhalfwidth.Powerfeedingis44VDC‐56VDC,Dualredundant
inputsthroughstandardadapters.
Figure4‐2:IDU‐H/HP
PoEdevicesarenotusedfortheRADWIN2000i.
