Radwin 2000+ SERIES User Manual

RADWIN2000+SeriesUserManual Release4.2.40 12‐3
GSUCommissioningandInstallation
• 1xGSU
• 1xGSUMountingKit
• 1xGPSAntenna
• 1xGPSAntennaMountingKit
• 1xRFCable,1.5m
• RADWINManagersuppliedeitheronCDorbyelectronicmeans
12.3.3GSUCommissioningandInstallation
PreparingtheGSUforUse
Atthedepot,logontotheunitusingLocalConnectionorIPaddress10.0.0.120tochangeits
IPaddressfromthedefault(10.0.0.120).ThemethodisthesameasisusedforanHBS.Inthe
examplescreencapturesbelow,weuse10.104.20.1withSubnetMask255.255.0.0and
Gateway10.104.10.21.
GSUInstallation
TheGSUlookslikeasmallformfactorODU.MountingtheGSUfollowsthestandardpattern.
TheGPSantennaismountedoutsideonawallorpole.
ConfiguringtheGSU
ToconfiguretheGSU,youlogontoit,exactlyasinRADWINManage r.
TheGSUMainWindow
HereisthemainwindowforGSUconfiguration:

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
