PoEDevices
4.8.4PoEDevices
TheexternalconnectionsfortheindoorPoEdeviceareshowninFigure 4‐39.
•ACPowerIN:ACpowerissuppliedhere.Thespecificadaptoriscountry‐dependent
•EthernetIN:InboundethernetRJ‐45connection
•PoEOUT:OutboundRJ‐45/CAT‐5ecabletooutdoorradiounit
Figure4‐39:ExternalConnections:PoEDevice
4.8.5IDU‐H/HP
TheexternalconnectionsfortheIDU‐H/HPareshowninFigure 4‐40.
•PoEtoradiounits:UsingaCAT‐5ecable,connecttheradiounitsthatarebeingsyn‐
chronizedhere.Upto6radiounitscanbeconnectedtooneIDU‐H/HP.
•DCinputprimary:Useonlyavendor‐approvedAC/DCadaptor.
•DCinputsecondary:Usedasabackupincaseofpowerfailure,connectabatteryto
thisinput(however,abatterycanbeusedforeithertheprimaryorsecondarypower
input).
•SFP1andSFP2:SFPconnection,eitherc opperorfiber
•LAN(x2):InputLAN/ethernetconnection
• Ground:Gr
oundcableisattachedtothegroundlug
EthernetIN
PoEOUT
ACPowerIN
