RADWIN2000+SeriesUserManual Release4.2.40 15‐5
ConfigurationofVLANTaggingforEthernetService
• TheoutertaghastobetheProvider’stag(sotheframeisnotfiltered)
• TheinternaltaghastobemanagementVLANID
Toavoidmix‐ups,bestpracticeisto:
• Separatethemanagementanddataports
• DefineonlyadataportwithProviderfunction
15.5.2ConfigurationofVLANTaggingforEthernetService
 TosetupanRT‐B(HSU)forVLANtagging:
1. OpenLinkConfiguration|EthernetandthenclicktheVLANConfigurationbutton.
InDisabledmode,Ethernetframespasstransparentlyovertheradiolinks.
2. ForPr ovidertagging,clicktheProviderRadiobutton:
InProvidermode,Ethernetframesaretaggedwiththeprovider’sVLANIDbefore
theyenterintotheprovider’snetwork/backbone.
3. EnteraProviderVLANIDandPriority.TheVLANIDmustbeintherange2to4094.
TheVLANPrioritymustbeintherange0to7.YoumayalsochangetheTPIDfrom
thedefaultasshown.
4. ClickOKtoaccept.
5. ForuserVLANtagging,clicktheTagRadiobutton:

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
