Radwin 2000+ SERIES User Manual

RADWIN2000+SeriesUserManual Release4.2.40 9‐3
HSSImplementation
Figure9‐3:CollocatedunitsusingHubSiteSynchronization(2)
9.3HSSImplementation
HSSisimplementedusingamaster(whichtransmitssynchronizationpulses),wheretherest
oftheco‐locatedunitsaredefinedasclients.Theseclientradiounitssynchronize their 
transmissiontothepulsesreceivedbythemaster.
HSScanbecarriedoutbetweenallco‐locatedRADWINradioproducts,solongastheyare
definedasabasestation.
9.3.1RadioFramePattern
Thesynchronizationsignalistransmittedonceperaspecifictimeperiod,anddetermines
whentheco‐locatedunits willtransmitandwhentheywillreceive.Thiscycleoftransmitand
receiveiscalledtheRadioFramePattern.Figure 9‐4showstheRadioFramePatternof3co‐
locatedoutdoorunits(ODUs).

Figure9‐4:RadioFr
amePattern
Ifthemasterisoneoftheco‐locatedODUs,itiscalledtheHubSiteMaster(HSM).Theother
co‐locatedODUsarecalledtheHubSiteClients(HSC).

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
