RADWIN2000+SeriesUserManual Release4.2.40 4‐33
LightningProtectionUnit(LPU)forCAT‐5eCables
Figure4‐46:GroundinganExternalAntenna
4.10.2LightningProtectionUnit(LPU)forCAT‐5eCables
LightningprotectionforCAT‐5ecablesisaccomplishedusingRADWIN’sLPU,asdescribed
here.
Table4‐3:LPUKitcontents
Item Qty View/Remarks
LPU 1
RJ‐45connectors 2
