RADWIN2000+SeriesUserManual Release4.2.40 9‐2
WhatisHubSiteSynchronization(HSS)?
Figure9‐1:Interferencecausedbycollocatedunits
ThisinterferencecanbemitigatedbyusingdifferentfrequenciesfortheUnit1/1Apairand
theUnit2/2Apair,butthisnotalwaysfeasible.
HubSiteSynchronization(HSS)isatechniquethatpreventsthisinterferencefromoccurring
withoutrequiringtheco‐locatedunitstousedifferentfr
equencies.Thissynchronization
ensuresthatallco‐locate dunitstransmitandreceiveatthesametime,asillustratedbelow:
Figure9‐2:CollocatedunitsusingHubSiteSynchronization(1)
Unit1
Unit2
Unit1A
Unit2A
