RADWIN2000+SeriesUserManual Release4.2.40 4‐7
Antennas
4.3.4Antennas
TheRADWIN2000A+,RADWIN2000C+,andRADWIN2000D+maybeoperatedwithan
integratedantennathatispartoftheradio,orwithexternalantennasconnectedtotheradio
viaN‐typeconnectors.TheRADWIN2000iusesexternalantennasonly. 
AllcablesandconnectionsmustbeconnectedcorrectlytoreduceRFlosses.Therequired
antennaimpedanceis50..
IntegratedAntennas
• The5.xGHzIntegratedAntennaunitisprovidedwitha370mm(1.2ft)flatpanel
antenna,withagainof23dBi(5.xGHz)/19dBi(4.9GHz)and8°beamwidth.
• The2.xGHzIntegratedAntennaODUisprovidedwith370mm(1.2ft)flatpanel
antenna,withagainof16dBiand16°beamwidth.Theradioandtheantennaare
housedinaweatherproofcaseasasingleunit.
ExternalAntennas
ExternalantennasareavailablefortheRADWIN2000+Seriesradios,varyinginoperating
frequencies,formfactor,sizeandgain,dualorsinglepolarization.
Figure4‐3:ExternalAntennasforusewithRADWIN2000+Series
SeetheRADWINproductscatalogforamoredetailedofferingofexternalantennas.
Atypicalantennakitcontains‐
• Anantenna
• TwoRFcables
• Mountingkit(seealsoMountinganExternalAntenna)
FlatAntenna DishAntenna MeshAntenna

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
