HardwareSetupforHubSiteSynchronization
Figure4‐41:ExternalConnections:RADWINGSU
4.9HardwareSetupforHubSite
Synchronization
Foracompletedescriptionofthefunctionalityofhubsitesynchronization,see Chapter9,
HubSiteSynchronization.
Here,wedescribehowtoconnectthevariousoptions:
• Serialhubsitesynchronization
• Ethernethubsitesynchronization
• GPShubsitesynchronizationwithanexternalGSU
• GPShubsitesynchronizationwhentheradiounitha
sanintegratedGPScapability(rele‐
vantfortheRADWIN2000ionly).
4.9.1SerialHubSiteSynchronization
SerialhubsitesynchronizationisThismethodisapplicablefortheRADWIN2000C+and
RADWIN2000D+only.
SerialhubsitesynchronizationrequirestheexternalHSSunit.Thegeneralconnections
betweenthetheHSSunitandtheradiounitsareshowninFigure 4‐42below.However,a
AllexternalODUportsshouldbewatersealed.SeeAdditionalConsiderationsfor
Waterproofingforinstructionsondoingso.
