Radwin 2000+ SERIES User Manual

RADWIN2000+SeriesUserManual Release4.2.40 2‐2
KeyfeaturesoftheRADWIN2000+Series
ThisreleasepresentsthecompleteRADWIN2000+Seriesinonepublication.
Feature4.2.40addsRADWIN’snewradiounit: Theall‐indoorRADWIN2000i.
2.3KeyfeaturesoftheRADWIN2000+Series
» Ethernetconnectivity
» AdvancedOFDM&MIMO2x2fornLOSperformance
» Enhancedinterferencemitigationcapability
» Inter&intrasitesynctoreduceselfinterference
» Regulationssupported‐FCC/IC/ETSI/WPC/MII/Universal
» Simpletodeploy
» WebInterfaceforlinkmanagement
» FullyintegratedwithRADWIN’sfamilyofsolutions:
• MasterODUofRADWIN2000+Serie scanco‐existwithotherMasterODUs,aswell
aswithbasestationsofallotherRADWINproducts
• CommonRADWINManager
• CommonRNMS
» SeparateuplinkanddownlinkconfigurableMaximumInformationRate(MIR)
2.4ComponentsofaRADWIN2000+Series
Link
2.4.1MajorComponents
Themajorelementofeachsiteistheradiotransceiver.
FortheRADWIN2000A+,RADWIN2000C+,andRADWIN2000D+,theradiounitis
connectedtoaPoEdevice.ThePoEprovidesanEthernetLANconnectiontouserequipment
(typicallyaswitch).
FortheRADWIN2000i,theradiounithasse
paratepowerandEthernetLANconnections.
2.4.2Accessories
Tobuild a2000+linkyouwi ll requiresomeofthefollowingaccessories:
• PoEdevices‐BothGigabitand100Mbps(notrelevantfortheRADWIN2000i)
• HSSunit‐Collocationunitforintra‐sitesynchronization(notrelevantfortheRADWIN
2000i)
• IDU‐H/HPAggregationunitforacollocatedhubsiteinsteadofmultiplePoEdevices
• GSUforinter‐sitesynchronization(notrelevantfortheRADWIN2000i)
