Preferences:Advanced
EnableRSSExtendedView:CheckingthisboxenablesadualchainviewforRSS.Disabled,the
RSSisshownasasing lebarforeachradio.Theeffectisvisibleimmediately.
Figure5‐13:RSSExtendedviewenabled
Figure5‐14:RSSExtendedviewdisabled
EnableTx/RxExtendedView:PlaceacheckmarkheretoenableviewingtheRxandTxrateof
eachLANlineattachedtotheunit.Disabled,therateshownisanaggregate
rateforbothLANlines.
Thiswillappearinallcases,butwillonlyhavemeaningifyourunithasmore
thanoneLANline,andiftheybothareconnected.See Chapter4,Hardware
Installationfortheexternalconnectionsoftheunityouareusing.
Figure5‐15:Tx/RxExtendedViewenabled
Figure5‐16:Tx/RxExtendedViewdisabled
EnableUnicodeinTextfields:Thisallowsyoutowritenon‐standardtextinthevariousfields
youuse.Wedonotrecommendthisbecauseitwouldbedifficultorimpossible
tocoordinatewithsystemsandequipmentthatma ynotbeabletodetectthis
text,andyoucouldthereforeloseconnections.
MapViewBackgroundMode:Youhaveachoiceoftwomapproviders,adefaultoraself‐
chosenbackground.IfyoulogonwithoutanInternetco nnection,youwillget
adefaultgraybackgroundor,ifyouhavecachingenabled,yourlastusedmap.
Ifyouwantabackgroundimageforthemapview,chooseBackgroundImage
thenclicktheexplorerbuttontoselectthelocationoftheimagefile.

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
