Radwin 2000+ SERIES - Basic Configuration for Operations; Figure 6-3 Main Window: Link; Registering the RT-B(HSU)

RADWIN2000+SeriesUserManual Release4.2.40 6‐12
RegisteringtheRT‐B(HSU)
Observethatundermanagementmode(notraffic)thethroughputandMCSismin‐
imaltosupportalinkandtheCBWisalsoatitsminimumforDBS.
12. IfyouareusingLocalConnection,logoutandlogbackintotheRT‐A(HBS)onitsIP
address.
Youmayha veobservedthatoperatingfrequency5.770GHzshown,isnotwhatwechose
(5.820GHz).TheRT‐A(HBS)triestooptimizethefrequencytominimizeinterferenceeffects.
WenextregisterandconfiguretheRT‐B(HSU).Manyoftheconfigurationandservice
parametersmaybesetpriortoregistration.Duringlinkestablishmenttheor derdoesnot
matter.However,manyconfigurationchangestoalinkafterregistration,willaffecttrafficor
evenresetthelink.
6.2.3RegisteringtheRT‐B(HSU)
Afterfewmoments,theregistrationprocesscompletes.Hereisthestatusofthelink:
Figure6‐3:Mainwindow:LinkMasterODUactivated,SlaveODUregistered
6.2.4BasicConfigurationforOperations
Severalbasicparametersshouldbeconfiguredforbothlinksites.Usetheappropriatesite
Configurationbutton:
