Radwin 2000+ SERIES User Manual

RADWIN2000+SeriesUserManual Release4.2.40 10‐2
ConnectinganHSSUnit
Figure10‐1:HSSInterconnectionUnit
 ToconnectanODUtoanHSSunit:
1. UnscrewtheprotectivecoverfromtheportmarkedSYNC1.
2. ConnecttheRJ‐45connectorfromoneendofthepreparedCAT‐5ecabletoSYNC1.
3. ConnecttheotherendoftheCAT‐5ecabletotheODUconnectorlabeledSYNC.
4. Tightenthepr
otectivesealthatisonthepreparedcableovertheRJ‐45connector.
5. RepeatforallODUsthataretobecollocatedatthehubsite.ThenextODUtobe
connectedisinsertedinSYNC1,SYNC2,followedbySYNC3andsoon.
• ForasingleHSSunit,ensurethatthecollocatedunitsareconnected
insequencefromSYNC1.IfanODUisremovedfromthehubsite,
thenallremainingODUsmustbereconnectedinordertomaintain
theconnectivity.
• Youmaycascade(daisy‐chain)twoormoreHSSUnitswithanHSS
cable.Themethodisdescribedindetailbelow.

Radwin 2000+ SERIES Specifications

General

Frequency Bands	5.4 GHz, 5.8 GHz
Channel Bandwidth	5 MHz, 10 MHz, 20 MHz
Encryption	AES-128
Interface	Ethernet
Operating Temperature	-30°C to +60°C
IP Rating	IP67
