RADWIN2000+SeriesUserManual Release4.2.40 12‐7
GSUCommissioningandInstallation
TheGPSSynctaballowsyoutochooseaRadioFramePattern(RFP)andsettheTransmission
Ratioforthesector.SeeseeRadioFramePatternonpage 9‐3foradescriptionofanRFP.
Choosethetransmissionratiobyclickingonitswindowandmovingthescrollbarrightorleft
withthekeyboardarrows.Becareful‐thisscrollbarissensitivetoevensmallmovementsof
themouse.
Thescreenaboveisforillustrativepurposesonly.Thelistunder“ProductFamily”
andtheavailableCBWcanvaryamongthevariousRADWIN2000+Series
products.
