DRUM SECTION
SM 3-75 C262/C265
Replacement
Adjustment
7. If the sensor input voltage is 3.0 volts or more, adjustment is completed.
8. If the sensor input voltage is less than 3.0 volts, adjust VR3 until the sensor
input voltage is 3.0 volts or more
9. Leave the SP mode.
