Ricoh LDD280 - ADF Stabilizer Installation

INSTALLATION PROCEDURE
SM 1-23 C262/C265
Installation
ADF stabilizer installation
1. Attach the two stabilizer brackets [A] to the back of the table using the
thumbscrews ( x 4).
2. Attach the caution label [B], as shown.
CAUTION
This procedure must be done to prevent the machine from falling
backwards when the ADF is open.
C262I020.WMFF
[A]
[B]
