MASTER EJECT
SM 6-29 C262/C265
Detailed
Descriptions
Master Eject Roller Unit Slide-out Mechanism
The master eject roller unit [A] can be slid out of the machine as shown for easy
master jam removal.
The unit contains the master pick-up roller, upper and lower master eject rollers,
and the master eject sensor.
C262D017.WMF
[A]
