SERVICE PROGRAM MODE
SM 5-33 C262/C265
Service
Tables
SP No. Display No. Menu
3 Shift Pressure Cam to A3
4 Shift Pressure Cam to A4
5 3
rd
Drum Position LED - GREEN
6 3
rd
Drum Position LED - RED
7 Printing Pressure 1
8 Printing Pressure 2
9 Printing Pressure 3
10 Printing Pressure 4
11 Printing Pressure 5
12 Printing Pressure 6
13 Printing Pressure 7
14 Pressure Cam Shift Motor FWD
15 Pressure Cam Shift Motor REV
1 Print Counter Up 5-070 Counter
2 Master Counter Up
1 All Indicators On
2 PSU Fan Motor
5-080 Other Sections - Main Body
3 Auto Shut Off
1 Slider Lift Motor - Up
2 Slider Lift Motor - Down
3 Job Separator Motor - Forward
5-090 Job Separator Unit
4 Job Separator Motor - Reverse
1 Feed Motor
2 Feed Clutch
5-100 Document Feeder Unit
3 Pick-up Solenoid
1 Paper End Solenoid
2 Paper Length Solenoid
3 Paper Table Motor Up
4 Paper Table Motor Down
5 Paper Feed motor
6 1st Paper Delivery motor
7 2nd Paper Delivery motor
5-150 LCIT
8 3rd Paper Delivery motor
1 Paper Table Motor Up 5-160 LCOT
2 Paper Table Motor Down
1 Count-up Key Counter
2 Count-up Key Card
5-170 Options
4 Not used
