SERVICE PROGRAM MODE
C262/C265 5-48 SM
22: 6-34 (Registration Roller Speed)
For accurate paper registration, the machine lowers the registration roller rotation
speed depending on the paper type selected by the user (standard, special, thick,
user 1, user 2). Usually, the ‘high’ speed setting (3% higher than the low) results in
better registration. However, when thick paper is used, it should be lowered
because thick paper strongly pushes the paper clamper. This causes friction to the
smooth rotation of the pressure cylinder due to play in the cylinder’s drive
transmission.
23: 6-59 (Filter Corrections)
The filter that is chosen depends on the original type that was selected at the
operation panel.
The standard settings are as follows:
• MTF: Letter mode and Pencil mode
• Adaptation: Letter/Photo mode and Pale mode
• Smoothing: Photo mode
Number Filter
0 -
1 MTF
2 Adaptation
3 Smoothing
