217
Effects List
fig.MFX-73
fig.MFX-74
fig.MFX-75
fig.MFX-76
73:
ENHANCER
FLANGER
(ENH
FLANGER)
Parameter
Value Description
Enh Sens #
0–127
Sensitivity of the enhancer
Enh Mix #
0–127
Level of the overtones generated
by the enhancer
Fln Pre Delay
0.0–100.0 ms
Adjusts the delay time from when
the direct sound begins until the
flanger sound is heard.
Fln Rate #
0.05–10.00 Hz,
note
Frequency of modulation
Fln Depth
0–127
Depth of modulation
Fln Feedback #
-98– +98%
Adjusts the proportion of the
flanger sound that is fed back into
the effect. Negative (-) settings will
invert the phase.
Fln Balance #
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
flanger (W) and the sound that is not
sent through the flanger (D).
Level
0–127
Output Level
74:
ENH
DELAY
(ENHANCER
DELAY)
Parameter
Value Description
Enh Sens #
0–127
Sensitivity of the enhancer
Enh Mix #
0–127
Level of the overtones generated
by the enhancer
Delay Time
0–2600 ms, note
Adjusts the delay time from the
direct sound until the delay
sound is heard.
Delay
Feedback #
-98– +98%
Adjusts the proportion of the de-
lay sound that is fed back into the
effect. Negative (-) settings will
invert the phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above
which sound fed back to the ef-
fect will be cut. If you do not want
to cut the high frequencies, set
this parameter to BYPASS.
Delay Balance #
D100:0W–D0:100W
Adjusts the volume balance be-
tween the sound that is sent
through the delay (W) and the
sound that is not sent through the
delay (D).
Level
0–127
Output Level
Feedback
Flanger
L in
R in
L out
R out
Mix
Mix
Enhancer
Enhancer
Balance W
Balance W
Balance D
Balance D
Feedback
Delay
L in
R in
L out
R out
Mix
Mix
Enhancer
Enhancer
Balance W
Balance W
Balance D
Balance D
75:
CHORUS
DELAY
Parameter
Value Description
Cho Pre Delay
0.0–100.0 ms
Adjusts the delay time from the di-
rect sound until the chorus sound is
heard.
Cho Rate #
0.05–10.00 Hz, note
Frequency of modulation
Cho Depth
0–127
Depth of modulation
Cho Balance #
D100:0W–D0:100W
Volume balance between the di-
rect sound (D) and the chorus
sound (W)
Delay Time
0–2600 ms, note
Adjusts the delay time from the di-
rect sound until the delay sound is
heard.
Delay
Feedback #
-98– +98%
Adjusts the proportion of the delay
sound that is fed back into the ef-
fect. Negative (-) settings will invert
the phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the
high frequencies, set this parame-
ter to BYPASS.
Delay
Balance #
D100:0W–D0:100W
Adjusts the volume balance be-
tween the sound that is sent
through the delay (W) and the
sound that is not sent through the
delay (D).
Level
0–127
Output Level
76:
FLANGER
DELAY
Parameter
Value Description
Fln Pre Delay
0.0–100.0 ms
Adjusts the delay time from when
the direct sound begins until the
flanger sound is heard.
Fln Rate #
0.05–10.00 Hz, note
Frequency of modulation
Fln Depth
0–127
Depth of modulation
Fln Feedback #
-98– +98%
Adjusts the proportion of the
flanger sound that is fed back into
the effect. Negative (-) settings will
invert the phase.
Fln Balance #
D100:0W–D0:100W
Volume balance between the di-
rect sound (D) and the flanger
sound (W)
Delay Time
0–2600 ms, note
Adjusts the delay time from the di-
rect sound until the delay sound is
heard.
Feedback
Delay
L in
R in
L out
R out
Balance W
Balance W
Balance D
Balance D
Chorus
Balance W
Balance W
Balance D
Balance D
Feedback
Delay
L in
R in
L out
R out
Balance W
Balance W
Balance D
Balance D
Flanger
Balance W
Balance W
Balance D
Balance D
Feedback
SonicCell_e.book 217 ページ 2007年8月9日 木曜日 午後9時17分
