Roland SonicCell User Manual

246
Model: SonicCell
Date: 2007.6.15
Version: 1.00
MIDI Implementation
1. Receive data
■ Channel Voice Messages
* Not received in Performance mode when the Receive Switch
parameter (Part Edit) is OFF.
● Note off
Status
2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note off velocity: 00H - 7FH (0 - 127)
* Not received when the Tone Env Mode parameter (Patch Ctrl and
Rhythm General) is NO-SUS.
● Note on
Status
2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
● Polyphonic Key Pressure
Status
2nd byte 3rd byte
AnH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = Polyphonic Key Pressure: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Receive Poly Key
Pressure parameter (Performance MIDI) is OFF.
● Control Change
* If the corresponding Controller number is selected for the Patch
Matrix Control Source parameter (Patch Mtrx Ctrl1-4), the
corresponding effect will occur.
* If a Controller number that corresponds to the System Control
Source 1, 2, 3 or 4 parameter (System Control) is selected, the
specified effect will apply if Patch Control Source 1, 2, 3 or 4
parameter (Patch Mtrx Ctrl1-4) is set to SYS CTRL1, SYS CTRL2,
SYS CTRL3 or SYS CTRL4.
❍ Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number:
00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received in Performance mode when the Receive Bank Select
(Performance MIDI) is OFF.
* The Performances, Patches, and Rhythms corresponding to each
Bank Select are as follows.
* The SRX series corresponding to each Bank Select are to see the
SRX series owner's manual.
BANK SELECT | PROGRAM | GROUP | NUMBER
MSB | LSB | NUMBER | |
-----+-----------+-----------+----------------------+-----------
000 | | 001 - 128 | GM Patch | 001 - 256
: | | | |
063 | | 001 - 128 | GM Patch | 001 - 256
085 | 000 | 001 - 064 | User Performance | 001 - 064
| 064 | 001 - 064 | Preset Performance | 001 - 064
086 | 000 | 001 - 032 | User Rhythm | 001 - 032
| 064 | 001 - 032 | Preset Rhythm | 001 - 032
087 | 000 | 001 - 128 | User Patch | 001 - 128
| 001 | 001 - 128 | User Patch | 129 - 256
| 064 | 001 - 128 | Preset Patch A | 001 - 128
| 065 | 001 - 128 | Preset Patch B | 001 - 128
| : | | : |
092 | 000 - | 001 - | SRX Rhythm | 001 -
| : | | : |
093 | 000 - | 001 - | SRX Patch | 001 -
| : | | : |
120 | | 001 - 057 | GM Rhythm | 001 - 009
121 | 000 - | 001 - 128 | GM Patch | 001 - 256
❍ Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Receive Modulation
parameter (Performance MIDI) is OFF.
❍ Breath type (Controller number 2)
Status 2nd byte 3rd byte
BnH 02H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Foot type (Controller number 4)
Status 2nd byte 3rd byte
BnH 04H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Portamento Time (Controller number 5)
Status 2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Portamento Time: 00H - 7FH (0 - 127)
* In Performance mode the Part Portament Time parameter (Part
Edit) will change.
❍ Data Entry (Controller number 6, 38)
Status
2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = the value of the parameter specified by RPN/NRPN
mm = MSB, ll = LSB
SonicCell_e.book 246 ページ ２００７年８月９日 木曜日 午後９時１７分
