Roland SonicCell - Checking the Installed Wave Expansion Boards

USER‘S GUIDE
48
After installation of the Wave Expansion Boards has been completed, check to confirm that the installed
boards are being recognized correctly.
Turn on the power, as described in “Turning the Power On” (p. 19 ).
fig.disp-Menu-left-Snd.eps
Press [MENU].
The Menu screen will appear.
fig.disp-menu-right-info.eps
Turn [CURSOR/VALUE] to select “SRX Info.”
fig.disp-SysSRXInfo.eps
Press [CURSOR/VALUE].
Press or to display System SRX Info screen.
The System screen will appear. Verify that the name of the
installed Wave Expansion Board is displayed.
Press [EXIT] to exit the System screen.
Checking the Installed Wave
Expansion Boards
1
12
3
4
NOTE
If “- - - - - - - ” appears next to the installed slot name, it’s possible that the installed Wave Expan-
sion Board is not being recognized correctly. Re-install the Wave Expansion Board correctly.
5
