249
MIDI Implementation
❍
RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers),
which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they
can be sent in any order) should be sent in order to select the
parameter, then Data Entry (Controller numbers 6 and 38) should be
sent to set the value. Once RPN messages are received, Data Entry
messages that is received at the same MIDI channel after that are
recognized as changing toward the value of the RPN messages. In
order not to make any mistakes, transmitting RPN Null is
recommended after setting parameters you need.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specified in
semitone steps.
* In Performance mode, the Part Bend Range parameter (Part Edit)
will change.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100
/ 8192 cent)
* In Performance mode, the Part Fine Tune parameter (Part Edit)
will change.
00H, 02H mmH, llH Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48
semitones)
ll: ignored (processed as 00H)
* In Performance mode, the Part Coarse Tune parameter (Part Edit)
will change.
00H, 05H mmH, llH Modulation Depth Range
mm: 00 00H - 06 00H
(0 - 16384 x 600 / 16384 cent)
* Not received in Patch mode.
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as
“unspecified.” Once this setting has
been made, subsequent Parameter
values that were previously set will
not change.
mm, ll: ignored
●
Program Change
Status
2nd byte
CnH ppH
n = MIDI channel number: 0H - FH (ch.1 - 16)
pp = Program number: 00H - 7FH (prog.1 - prog.128)
* Not received in Performance mode when the Receive Program
Change parameter (Performance MIDI) is OFF.
●
Channel Pressure
Status
2nd byte
DnH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Channel Pressure: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Receive Channel
Pressure parameter (Performance MIDI) is OFF.
●
Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value:
00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
* Not received when the Tone Receive Bender parameter (Patch
Ctrl) is OFF.
* Not received in Performance mode when the Receive Pitch Bend
parameter (Performance MIDI) is OFF.
■
Channel Mode Messages
* Not received in Performance mode when the Receive Switch
parameter (Part Edit) is OFF.
●
All Sounds Off (Controller number 120)
Status 2nd byte 3rd byte
BnH 78H 00H
n = MIDI channel number: 0H - FH (ch.1 - 16)
* When this message is received, all notes currently sounding on the
corresponding channel will be turned off.
SonicCell_e.book 249 ページ ２００７年８月９日 木曜日 午後９時１７分
