MIDI Implementation
■ System Exclusive Message
Status
Data byte Status
F0H iiH, ddH, ......,eeH F7H
F0H: System Exclusive Message status
ii = ID number: an ID number (manufacturer ID) to indicate the
manufacturer whose Exclusive message this is.
Roland's manufacturer ID is 41H.
ID numbers 7EH and 7FH are extensions of the
MIDI standard; Universal Non-realtime
Messages (7EH) and Universal Realtime
Messages (7FH).
dd,...,ee = data: 00H - 7FH (0 - 127)
F7H: EOX (End Of Exclusive)
Of the System Exclusive messages received by this device, the
Universal Non-realtime messages and the Universal Realtime
messages and the Data Request (RQ1) messages and the Data Set
(DT1) messages will be set automatically.
● Universal Non-realtime System Exclusive
Messages
❍ Identity Request Message
Status
Data byte Status
F0H 7EH, dev, 06H, 01H F7H
Byte
Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
dev Device ID (dev: 10H - 1FH, 7FH)
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End Of Exclusive)
* When this message is received, Identity Reply message (p. 256)
will be transmitted.
❍ GM1 System On
Status Data byte Status
F0H 7EH, 7FH, 09H, 01H F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
01H Sub ID#2 (General MIDI 1 On)
F7H EOX (End Of Exclusive)
* When this messages is received, this instrument will turn to the
Performance mode.
* Not received when the Receive GM1 System On parameter
(System MIDI) is OFF.
❍ GM2 System On
Status
Data byte Status
F0H 7EH 7FH 09H 03H F7H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
03H Sub ID#2 (General MIDI 2 On)
F7H EOX (End Of Exclusive)
* When this messages is received, this instrument will turn to the
Performance mode.
* Not received when the Receive GM2 System On parameter
(System MIDI) is OFF.
❍ GM System Off
Status Data byte Status
F0H 7EH, 7F, 09H, 02H F7H
Byte
Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
7FH Device ID (Broadcast)
09H Sub ID#1 (General MIDI Message)
02H Sub ID#2 (General MIDI Off)
F7H EOX (End Of Exclusive)
* When this messages is received, this instrument will return to the
Performance mode.
●
Universal Realtime System Exclusive Messages
❍ Master Volume
Status Data byte Status
F0H 7FH, 7FH, 04H, 01H, llH, mmH F7H
Byte
Explanation
F0H Exclusive status
7FH ID number (universal realtime message)
7FH Device ID (Broadcast)
04H Sub ID#1 (Device Control)
01H Sub ID#2 (Master Volume)
llH Master Volume lower byte
mmH Master Volume upper byte
F7H EOX (End Of Exclusive)
* The lower byte (llH) of Master Volume will be handled as 00H.
* The Master Level parameter (System) will change.
