Roland SonicCell User Manual

257
MIDI Implementation
3. Parameter Address Map
* Transmission of “#” marked address is divided to some packets.
For example, ABH in hexadecimal notation will be divided to
0AH and 0BH, and is sent/received in this order.
* “<*>” marked address or parameters are ignored when the
SonicCell received them.
1. Sonic Cell (ModelID = 00H 00H 25H)
+------------------------------------------------------------------------------+
| Start | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 01 00 00 00 | Setup |
|-------------+----------------------------------------------------------------|
| 02 00 00 00 | System |
|-------------+----------------------------------------------------------------|
| 10 00 00 00 | Temporary Performance |
| 11 00 00 00 | Temporary Patch/Rhythm (Performance Mode Part 1) |
| 11 20 00 00 | Temporary Patch/Rhythm (Performance Mode Part 2) |
| : | |
| 14 60 00 00 | Temporary Patch/Rhythm (Performance Mode Part 16) |
| 1F 00 00 00 | Temporary Patch/Rhythm (Patch Mode) |
|-------------+----------------------------------------------------------------|
| 20 00 00 00 | User Performance (01) |
| 20 01 00 00 | User Performance (02) |
| : | |
| 20 3F 00 00 | User Performance (64) |
|-------------+----------------------------------------------------------------|
| 30 00 00 00 | User Patch (001) |
| 30 01 00 00 | User Patch (002) |
| : | |
| 31 7F 00 00 | User Patch (256) |
|-------------+----------------------------------------------------------------|
| 40 00 00 00 | User Rhythm Set (001) |
| 40 10 00 00 | User Rhythm Set (002) |
| : | |
| 43 70 00 00 | User Rhythm Set (032) |
+------------------------------------------------------------------------------+
* System
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | System Common |
| 00 02 00 | System Mastering |
| 00 03 00 | System External Input |
+------------------------------------------------------------------------------+
* Temporary Patch/Rhythm
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Temporary Patch |
| 10 00 00 | Temporary Rhythm |
+------------------------------------------------------------------------------+
* Performance
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Performance Common |
| 00 02 00 | Performance Common MFX1 |
| 00 04 00 | Performance Common Chorus |
| 00 06 00 | Performance Common Reverb |
| 00 08 00 | Performance Common MFX2 |
| 00 0A 00 | Performance Common MFX3 |
| 00 10 00 | Performance MIDI (Channel 1) |
| 00 11 00 | Performance MIDI (Channel 2) |
| : | |
| 00 1F 00 | Performance MIDI (Channel 16) |
| 00 20 00 | Performance Part (Part 1) |
| 00 21 00 | Performance Part (Part 2) |
| : | |
| 00 2F 00 | Performance Part (Part 16) |
| 00 60 00 | Performance Controller |
+------------------------------------------------------------------------------+
* Patch
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Patch Common |
| 00 02 00 | Patch Common MFX |
| 00 04 00 | Patch Common Chorus |
| 00 06 00 | Patch Common Reverb |
| 00 10 00 | Patch TMT (Tone Mix Table) |
| 00 20 00 | Patch Tone (Tone 1) |
| 00 22 00 | Patch Tone (Tone 2) |
| 00 24 00 | Patch Tone (Tone 3) |
| 00 26 00 | Patch Tone (Tone 4) |
+------------------------------------------------------------------------------+
* Rhythm
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 00 | Rhythm Common |
| 00 02 00 | Rhythm Common MFX |
| 00 04 00 | Rhythm Common Chorus |
| 00 06 00 | Rhythm Common Reverb |
| 00 10 00 | Rhythm Tone (Key # 21) |
| 00 12 00 | Rhythm Tone (Key # 22) |
| : | |
| 01 3E 00 | Rhythm Tone (Key # 108) |
+------------------------------------------------------------------------------+
* Setup
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 0aaa | Sound Mode (0 - 4) |
| | | PATCH, PERFORM, GM1, GM2, GS |
|-------------+-----------+----------------------------------------------------|
| 00 01 | 0aaa aaaa | Performance Bank Select MSB (CC# 0) (0 - 127) |
| 00 02 | 0aaa aaaa | Performance Bank Select LSB (CC# 32) (0 - 127) |
| 00 03 | 0aaa aaaa | Performance Program Number (PC) (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 04 | 0aaa aaaa | Patch Bank Select MSB (CC# 0) (0 - 127) |
| 00 05 | 0aaa aaaa | Patch Bank Select LSB (CC# 32) (0 - 127) |
| 00 06 | 0aaa aaaa | Patch Program Number (PC) (0 - 127) |
| 00 07 | 0aaa aaaa | (reserve) <*> |
| 00 08 | 0aaa aaaa | (reserve) <*> |
| 00 09 | 0aaa aaaa | (reserve) <*> |
|-------------+-----------+----------------------------------------------------|
| 00 0A | 0000 000a | MFX1 Switch (0 - 1) |
| | | BYPASS, ON |
| 00 0B | 0000 000a | MFX2 Switch (0 - 1) |
| | | BYPASS, ON |
| 00 0C | 0000 000a | MFX3 Switch (0 - 1) |
| | | BYPASS, ON |
| 00 0D | 0000 000a | Chorus Switch (0 - 1) |
| | | OFF, ON |
| 00 0E | 0000 000a | Reverb Switch (0 - 1) |
| | | OFF, ON |
| 00 0F | 0000 000a | Input Effect Switch (0 - 1) |
| | | OFF, ON |
| 00 10 | 0000 000a | (reserve) <*> |
| 00 11 | 0000 000a | (reserve) <*> |
| 00 12 | 0000 aaaa | (reserve) <*> |
| 00 13 | 0000 0aaa | (reserve) <*> |
|-------------+-----------+----------------------------------------------------|
| 00 14 | 0000 0aaa | (reserve) <*> |
| 00 15 | 0000 00aa | (reserve) <*> |
| 00 16 | 0000 000a | (reserve) <*> |
| 00 17 | 0aaa aaaa | (reserve) <*> |
| 00 18 | 0aaa aaaa | (reserve) <*> |
| 00 19 | 0000 000a | (reserve) <*> |
| 00 1A | 0aaa aaaa | (reserve) <*> |
| 00 1B | 0aaa aaaa | (reserve) <*> |
| 00 1C | 0aaa aaaa | (reserve) <*> |
| 00 1D | 0000 0aaa | (reserve) <*> |
| 00 1E | 0000 000a | (reserve) <*> |
| 00 1F | 0aaa aaaa | (reserve) <*> |
| 00 20 | 0aaa aaaa | (reserve) <*> |
| 00 21 | 0000 000a | (reserve) <*> |
| 00 22 | 0aaa aaaa | (reserve) <*> |
|# 00 23 | 0000 aaaa | |
| | 0000 bbbb | (reserve) <*> |
| 00 25 | 0000 000a | (reserve) <*> |
| 00 26 | 0aaa aaaa | (reserve) <*> |
| 00 27 | 0aaa aaaa | (reserve) <*> |
| 00 28 | 0aaa aaaa | (reserve) <*> |
|-------------+-----------+----------------------------------------------------|
| 00 29 | 0000 000a | (reserve) <*> |
| 00 2A | 0aaa aaaa | (reserve) <*> |
| 00 2B | 00aa aaaa | (reserve) <*> |
|-------------+-----------+----------------------------------------------------|
| 00 2C | 0000 000a | (reserve) <*> |
| 00 2D | 0000 000a | (reserve) <*> |
