Nur für den internen Gebrauch Boards for HiPath 3000
Peripheral boards
LED statuses and their meanings
Cable and connector assignment
● For connecting to the SIVAPAC connector on the backplane: Table 3-87
● For connecting to the connector panels using RJ45 jacks: Table 3-88
● For U.S. only: For connecting to the connector panels with CHAMP jack: Table 3-89
● For connecting to the connector panels using SIPAC 1 SU connectors: Table 3-90 and
Table 3-91
Table 3-86 SLMAV8, SLMAV24 – LED statuses
Red LED Green
LED
Status Action
Off Off Board not receiving power or not plugged in
correctly.
Board is out of order.
Check plug contact on
board.
On Flashing Board performs a self-test.
Slow
flashing
Off Board is faulty. Replace board.
Fast
flashing
Off Loadware is being loaded.
Off On Loading was successfully completed and
board is OK (idle state). No subscriber line
circuit is active.
Off Flashing At least one subscriber line circuit is activat-
ed.
On On Unrecoverable hardware or loadware error Replace board.
