Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-384 HiPath 3000/5000 V9, Service documentation
boards.fm
Options
Two -48-V lines fused using a PTC resistor are available for external applications. The voltage
is picked up by the MDFU-E (Table 3-183: M48VF1 / 0V_F and M48VF2 / 0V_F). Each trunk
has a maximum load capacity of 300 mA.
Figure 3-145 REALS (S30807-Q6629-X)
To the SIPAC 4SU connector X17
Signals are picked up via SIVAPAC con-
nector X116 on the backplane.
Removal tab
You can insert a screwdriver here to remove REALS from the shelf.
