Digital Modules
3-73
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Terminal assignment and block diagram of the SM 322; DO 8 x 24 VDC/0.5 A
Channel number, channel fault (F)
Status display – green
SF
F0
0
F1
1
F2
2
F3
3
F4
4
F5
5
F6
6
F7
7
Fault indicator – red
Connection Diagram
Figure 3-25 Module view of the SM 322; DO 8 24 V DC/0.5 A
