Siemens SIMATIC S7-300 Module data Reference Manual

SIMATIC TOP Connect and SIMATIC TOP Connect TPA
8-12
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
8.3 Wiring SIMATIC TOP Connect with Digital Modules
Introduction
For wiring the module with actuators/sensors using SIMATIC TOP connect, you
must first select the components as a function of the module and method of
connection (screw type or spring-loaded terminal, one-conductor, three-conductor
or 2A connection; relay).
8.3.1 SIMATIC TOP Connect Components and Selection Aid
Components
The following table contains all the component of SIMATIC TOP connect.
Table 8-5 Components of SIMATIC TOP connect
Components of SIMATIC TOP connect
Order number
Terminal
block
... for one-conductor
connection
Spring-loaded screw-type 6ES7924-0AA00-0AB0
6ES7924-0AA00-0AA0
... for one-conductor
connection (10 items)
Spring-loaded screw-type 6ES7924-0AA00-1AB0
6ES7924-0AA00-1AA0
... for three-conductor
connection
Spring-loaded screw-type 6ES7924-0CA00-0AB0
6ES7924-0CA00-0AA0
... for three-conductor
connection (10 items)
Spring-loaded screw-type 6ES7924-0CA00-1AB0
6ES7924-0CA00-1AA0
... for 2A modules Spring-loaded screw-type 6ES7924-0BB00-0AB0
6ES7924-0BB00-0AA0
... for 2A modules (10 items) Spring-loaded screw-type 6ES7924-0BB00-1AB0
6ES7924-0BB00-1AA0
... for relays Spring-loaded screw-type 6ES7924-0CD00-0AB0
6ES7924-0CD00-0AA0
Front
connector
for 32-channel modules
(refer to Figure 8-4)
Voltage supply via:
Spring-loaded terminals 6ES7921 3AA20-0AA0
for 16-channel modules Voltage supply via:
spring-loaded screw-type 6ES7921-3AA00-0AA0
6ES7921-3AB00-0AA0
for 16-channel 2A modules Voltage supply via:
spring-loaded screw-type 6ES7921-3AC00-0AA0
6ES7921-3AD00-0AA0
Connectors (plug-in connectors), set of 8 (insulation displacement
connectors)
6ES7921-3BE10-0AA0
Round-sheat
h
ribbon cable
1 x 16
Unshielded 30 m
60 m
6ES7923-0CD00-0AA0
6ES7923-0CG00-0AA0
1 x 16
Shielded 30 m
60 m
6ES7923-0CD00-0BA0
6ES7923-0CG00-0BA0
