Siemens SIMATIC S7-300 Module data - C.3 Dimension Drawings of the Interface Modules

Dimension Drawings
C-13
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
C.3 Dimension Drawings of the Interface Modules
IM 360
Figure C-17 shows the dimension drawing of the interface module IM 360.
125
12040
Figure C-17 Interface Module IM 360
IM 361
Figure C-18 shows the dimension drawing of the interface module IM 361.
125
120
80
Figure C-18 Interface Module IM 361
