Siemens SIMATIC S7-300 Module data - Analog Value Representation in Output Range +10; Analog Value Representation in Output Range +20 Ma; Analog Value Representation in Output Ranges 0 and 20 Ma

Analog Modules
4-26
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Analog Value Representation in Voltage Output Ranges
Table 4-34 Analog Value Representation in Output Range ±10 V
System Voltage Output Range
Dec. hex. ±10 V
118.5149% 32767 7FFF 0.00 V Overflow, off circuit and de-energized
32512 7F00
117.589% 32511 7EFF 11.76 V Overrange
27649 6C01
100 % 27648 6C00 10 V
75% 20736 5100 7.5 V
0.003617% 1 1 361.7 µV Rated range
0 % 0 0 0 V
–1 FFFF –361.7 µV
–75 % –20736 AF00 –7.5 V
–100 % –27648 9400 –10 V
–27649 93FF Underrange
–117.593% –32512 8100 –11.76 V
–32513 80FF Underflow, off circuit and de-energized
–118.519% –32768 8000 0.00 V
Table 4-35 Analog Value Representation in Output Ranges 0 to 10 V and 1 to 5 V
System Voltage Output Range
Dec. hex. 0 to 10 V 1 to 5 V
118.5149% 32767 7FFF 0.00 V 0.00 V Overflow, off circuit and de
-
energized
32512 7F00
energized
117.589% 32511 7EFF 11.76 V 5.70 V Overrange
27649 6C01
100 % 27648 6C00 10 V 5 V
75% 20736 5100 7.5 V 3.75 V
0.003617% 1 1 361.7µV 1V+144.7µV Rated range
0 % 0 0 0 V 1 V
–1 FFFF Underrange
–25 % –6912 E500 0 V
–6913 E4FF Not possible.
The output value is limited
–117.593% –32512 8100
The output value is limited
to 0 V.
–32513 80FF Underflow, off circuit and
de-energized
–118.519% –32768 8000 0.00 V 0.00 V
de-energized
