Siemens SIMATIC S7-300 Module data Reference Manual

Analog Modules
4-43
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
4.7.2 Parameters of the Analog Output Modules
The analog output modules use a subset of the parameters and ranges of values
listed in the table below, depending on the functionality. Refer to the section on the
module concerned, starting from Section 4.28, for the subset “mastered” by the
specific analog modules.
The default settings apply if you have not performed parameter assignment in
STEP 7.
Table 4-42 Parameters of the Analog Output Modules
Parameter
Value Range Default
Settings
Para-
meter Type
Scope
Enable
• Diagnostic
interrupt
Yes/no No Dynamic Module
Diagnostics
• Group diagnostics Yes/no No Static Channel
Output
• Output type Deactivated
Voltage
Current
U
Dynamic Channel
• Output range For the settable measuring ranges of the
output channels, please refer to the
individual module description.
"10 V
Response with
CPU-STOP
ASS Outputs de-energized
LWH Hold last value
EWS Apply substitute value
ASS
Dynamic Channel

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
