Parameter Sets for Signal Modules

A-43

Programmable Logic Controllers S7-300 Module Data

A5E00105505-03

Measuring methods and measuring ranges

The table below contains all the measuring methods and measuring ranges of the

analog input/output modules and their codes. You must enter these codes in bytes

2 to 5 of data record 1 (refer to Figure A-19).

Table A-33 Codes for the Measuring Ranges of the Analog Input/Output Modules

Measuring Method

Code Measuring Range Code

Deactivated 2#0000 Deactivated 2#0000

Voltage 2#0001 0 to 10 V 2#1000

Resistance, four-conductor connection 2#0100 10 k 2#1001

Thermal resistance + linearization

four-conductor connection

2#1000 Pt 100 climate 2#0000

Output methods and output ranges

The table below contains all the output methods and output ranges of the analog

input/output modules and their codes. You must enter these codes in bytes 6 and 7

of data record 1 (refer to Figure A-19).

Table A-34 Codes for the Output Ranges of the Analog Input/Output Modules

Output type

Code Output Range Code

Deactivated 2#0000 Deactivated 2#0000

Voltage 2#0001 0 to 10 V 2#1000
