Siemens SIMATIC S7-300 Module data Reference Manual

Analog Modules
4-11
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Measured-value resolution
The resolution of the analog values may differ, depending on the analog module
and its parameterization. With resolutions < 15 bits, the bits indicated by “x” are set
to “0”.
Note: This resolution does not apply to temperature values. The converted
temperature values are the result of a conversion in the analog module (see Tables
4-16 to 4-31).
Table 4-7 Possible analog value resolutions
Resolution
in bits (+ sign)
Units Analog value
in bits (+ sign)
decimal hexadecimal High-Order Byte Low-Order Byte
8 128 80
H
Sign 0 0 0 0 0 0 0 1 x x x x x x x
9 64 40
H
Sign 0 0 0 0 0 0 0 0 1 x x x x x x
10 32 20
H
Sign 0 0 0 0 0 0 0 0 0 1 x x x x x
11 16 10
H
Sign 0 0 0 0 0 0 0 0 0 0 1 x x x x
12 8 8
H
Sign 0 0 0 0 0 0 0 0 0 0 0 1 x x x
13 4 4
H
Sign 0 0 0 0 0 0 0 0 0 0 0 0 1 x x
14 2 2
H
Sign 0 0 0 0 0 0 0 0 0 0 0 0 0 1 x
15 1 1
H
Sign 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
