An overview of the parameters that you can set and their default settings are
shown in the table below.
Table 4-54 Parameters of the SM 331; AI 8 x 16 bits
Parameter
Value Range Default
settings
Para-
meter Type
Scope
Parameter
Value Range
Default
settings
Para-
meter Type
Scope
Enable
• Hardware interrupt if
the limit value is
exceeded
• Hardware interrupt at
end of cycle
• Diagnostic interrupt
Yes/no
Yes/no
Yes/no
No
No
No
Dynamic
Dynamic
Dynamic
Module
Hardware interrupt trigger
• Upper limit
• Lower limit
32511 to –32512
–32512 to 32511
–
–
Dynamic
Dynamic
Channel
Channel
Diagnostics
• Group diagnostics
• Wire-Break Check
Yes/no
Yes/no
No
No
Static Channel
Channel
Measurement
• Module mode
• Interference
Suppression
• 8 channels
• 4 channels
50 Hz
60 Hz
400 Hz
50/60/400 Hz
Yes
No
50/60/400 Hz
Dynamic Module
Channel
group
• Smoothing • None
• Low
• Average
• High
None Dynamic Channel
group
• Measuring Method • Measuring
Range:
Dynamic Channel
group
Deactivated
Voltage • $ 5 V
• 1 to 5 V
• $ 10 V
$ 10 V
Current (4-wire
transmitter)
• 0 to 20 mA
• 4 to 20 mA
• $ 20 mA
4 to 20 mA
