3.33.1 Assigning Parameters to the SM 327; DI 8/DX 8 x VDC 24/0.5 A
Parameter assignment
You will find a description of the general procedure for assigning parameters to
digital modules in Section 3.3.
Parameters of the SM 327; DI 8/DX 8 x DC 24 V/0.5 A, parameterizable
You will find an overview of the parameters that you can set and their default
settings for the SM 327; DI 8/DX 8 x VDC 24/0.5 A in the table below.
The default settings apply if you have not performed parameter assignment in
STEP 7.
You will see which parameters you can modify from the list:
• In STEP 7
• With SFC 55 “WR_PARM”
• with SFB 53 “WRREC” (e. g. for GSD).
The parameters set with STEP 7 can also be transferred with SFCs 56 and 57 and
the SFB 53 to the module (refer to the STEP 7 manuals).
Table 3-28 Parameters of the SM 327; DI 8/DX 8 VDC 24/0.5 A
Parameter
Value
Range
Default
Settings
Paramete
r
Type
Scope Data
Record
No.
Parameters can be
assigned with ...
No.
SFC 55,
SFB 53
Program
ming
device
Digital output Yes/no No Dynamic Channel 1 Yes Yes
