Table 4-65 Parameters of the SM 331; AI 8 x 12 bits, continued
Parameter ScopePara-
meter
Type
Default
Settings
Value Range
Measurement
• Measuring Method Deactivated
U Voltage
4DMU Current (4-wire transmitter)
2DMU Current (2-wire transmitter)
R-4L Resistance
(four-conductor connection)
RTD-4L Bulb resistor
(linear, four-conductor
connection)
TC-I Thermocouple
(internal comparison)
TC-E Thermocouple
(external comparison)
TC-IL Thermocouple
(linear, internal comparison)
TC-EL Thermocouple
(linear, external comparison)
U
Dynamic
Channel o
r
Channel
group
• Measuring Range Refer to Section 4.22.2 for the
measuring ranges of the input
channels that you can set.
"10 V
• Interference
Suppression
400 Hz; 60 Hz; 50 Hz; 10 Hz 50 Hz
Channel groups
The channels of the SM 331; AI 8 x 12 bits are arranged in four groups of two. You
can only ever assign parameters to one channel group.
The analog input module SM 331; AI 8 x 12 bits has a measuring range module for
each channel group.
The table below shows which channels are parameterized as a channel group in
each case. You will need the channel group number to set the parameters in the
user program with an SFC.
Table 4-66 Assignment of Channels of the SM 331; AI 8 x 12 bits to Channel Groups
Channels ...
... form one Channel Group each
Channel 0
Channel group 0
Channel 1
Channel group 0
Channel 2
Channel group 1
Channel 3
Channel group 1
Channel 4
Channel group 2
Channel 5
Channel group 2
Channel 6
Channel group 3
Channel 7
Channel group 3
