Page #509 background imageLoading...
Page #509 background image
Parameter Sets for Signal Modules
A-41
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Output method and output range
The following table contains all the output methods and output ranges of the
SM 332; AO 8 x 12 bits , with their coding. You must enter these codes in bytes 2
to 9 of data record 1 (refer to FigureA-18).
Table A-31 Codes for the output ranges of the analog output module SM332;
AO 8 x 12 bits
Output type
Code Output range Code
Deactivated 2#0000 Deactivated 2#0000
Voltage 2#0001 1 to 5 V
0 to 10 V
± 10 V
2#0111
2#1000
2#1001
Current 2#0010 0 to 20 mA
4 to 20 mA
± 20 mA
2#0010
2#0011
2#0100
A.11 Parameters of the Analog Input/Output Modules
Parameters
The table below contains all the parameters you can set for analog input/output
modules.
You will see which parameters you can modify from the list:
In STEP 7
With SFC 55 “WR_PARM”
The parameters set with STEP 7 can also be transferred with SFCs 56 and 57 to
the module (refer to the STEP 7 manuals).
Table A-32 Parameters of the Analog Input/Output Modules
Parameter
Data Record
No.
Parameters can be assigned
with ...
... SFC 55 ...
Programming
Device
Measuring Method Yes Yes
Measuring Range Yes Yes
Integration Time
1
Yes Yes
Output type
1
Yes Yes
Output Range Yes Yes
