General Technical Specifications
1-10
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Ambient mechanical conditions
The ambient mechanical conditions for S7-300 modules are listed in the following
table in the form of sinusoidal oscillations.
Table 1-5 Mechanical Conditions
Frequency Range
in Hz
Continuous Occasional
10 v f v 58 0.0375 mm amplitude 0.075 mm amplitude
58 v f v 150 0.5 g constant acceleration 1 g constant acceleration
Reducing vibrations
If your S7-300 modules are exposed to severe shock and/or vibrations, you must
take the appropriate measures to reduce the acceleration and/or amplitude,
respectively.
We recommend that you install the S7-300 on vibration-damping materials
(for example, rubber-metal antivibration mountings).
Ambient mechanical conditions test
The following table contains important information on the type and scope of tests
for ambient mechanical conditions.
Table 1-6 Ambient Mechanical Conditions Test
Test ...
Test Standard Remarks
Vibrations Vibration test accor-
ding to IEC 60068
Part 2-6 (sinusoidal)
Type of oscillation: frequency sweeps with a rate of
change of 1 octave/minute.
10 Hz v f v 58 Hz, constant amplitude of
0.075 mm
58 Hz v f v 150 Hz, constant acceleration of 1 g
Duration of oscillation: 10 frequency sweeps per
axis in each of three axes perpendicular to each
other
Shock Shock test to
IEC 60068, Part 2-29
Type of shock: half-sine
Severity of shock: 15 g peak value, 11 ms duration
Direction of shock: 3 shocks each in the +/– direc-
tion in each of three axes perpendicular to each
other
