Analog Modules

4-10

Programmable Logic Controllers S7-300 Module Data

A5E00105505-03

Example

In the following example you can see how the positions not padded with “0” are

written for low resolution.

Table 4-6 Example: Bit pattern of a 16-bit and a 13-bit analog value

Resolution

Analog value

Bits 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

16-bit analog value 0 1 0 0 0 1 1 0 0 1 1 1 0 0 1 1

13-bit analog value 0 1 0 0 0 1 1 0 0 1 1 1 0 0 0 0

4.3.1 Analog Value Representation for Analog Input Channels

Introduction

The tables in this chapter contain the measured value representations for the

various measuring ranges of the analog input modules. The values in the tables

apply to all modules with the corresponding measuring ranges.

Notes for readers of the tables

Tables 4-8 to 4-9 contain the binary representation of the measured values.

Since the binary representation of the measured values is always the same,

starting at 4-10 these tables only contain the measured values and the units.
