Siemens SIMATIC S7-300 Module data Reference Manual

A-26
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Reaction to open thermocouple of the SM 331; AI 8 x TC
The table below contains the codes for the reactions to an open thermocouple,
which you enter in the corresponding byte of data record 128 (refer to Figure A-9).
Table A-17 Codes of Reaction to Open Thermocouple of the SM 331; AI 8 x TC
Reaction to open thermocouple Code
Overflow 2#0
Underflow 2#1
Smoothing of the SM 331; AI 8 x TC
The table below contains the codes for all smoothing modes, which you enter in
the corresponding byte of data record 128 (refer to Figure A-9).
Table A-18 Codes Smoothing of the SM 331; AI 8 x TC
Smoothing Code
None 2#00
Low 2#01
Average 2#10
High 2#11

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
