Analog Modules
4-185
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Data for Selecting an Actuator
Output ranges (rated values)
• Voltage ±10 V
0 to 10 V
1 to 5 V
• Current ±20 mA
0 to 20 mA
4 to 20 mA
Load resistance (in the nominal
range of the output)
• For voltage outputs
– capacitive load
min. 1 kΩ
max. 1 µF
• For current outputs
–At U
CM
< 1V
– Inductive load
max. 500 Ω
max. 600 
max. 10 mH
Voltage outputs
• Short-circuit protection
• Short-circuit current
Yes
max. 25 mA
Current outputs
• No-load voltage max. 18 V
Destruction limit against
voltages/currents applied from
outside
• Voltage at outputs to M
ANA
max. 18 V continuous;
75 V for max. 1 s (duty
factor 1:20)
• Current max. 50 mA DC
Connection of actuators
• For voltage output
– Two-conductor
connection
– Four-conductor
connection
(measuring circuit)
Possible
Possible
• For current output
– Two-conductor
connection
Possible
4.29.1 Commissioning the SM 332; AO 2 x 12 bits
Note
When switching on and off the rated load voltage (L+), wrong intermediate values
can occur across the output for approximately 10 ms.
Parameter
You will find a description of the general procedure for assigning parameters to
analog modules in Section 4.7.
You will find an overview of the programmable parameters and their default values
in Table 4-42, on page 4-43.
