Siemens SIMATIC S7-300 Module data - C-16 Dimension Drawing of the Power Supply Module PS 307; 5 a with Cpus 313;314;315;315-2 DP. Side View

C-12
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
PS 307; 5 A with CPUs 313/314/315/315-2 DP
Figure C-16 shows the dimension drawing of the power supply module PS 307; 5 A
with the CPUs 313/314/315/315-2 DP in the side view.
125
13
130
120
6
Figure C-16 Dimension Drawing of the Power Supply Module PS 307; 5 A with CPUs
313/314/315/315-2 DP. Side View
