Analog Modules
4-8
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
4.2 Sequence of Steps from Choosing to Commissioning the
Module
Introduction
The following table contains the tasks that you have to perform one after the other
to commission analog modules successfully.
The sequence of steps is a suggestion, but you can perform individual steps either
earlier or later (for example, assign parameters to the module) or install other
modules or install, commission etc. other modules in between times.
Sequence of steps
Table 4-5 Sequence of Steps from Choosing to Commissioning the Analog Module
Step Procedure Refer To...
1. Select the module Section 4.1 and specific module section from
Section 4.22
2. With some analog input
modules: set the measuring
method and measuring range by
means of the measuring range
module
Section 4.4
3. Install the module in the
SIMATIC S7 network
”Mounting” section in the Installation Manual for
the programmable logic controller being used:
• S7-300 Programmable Controllers, Hardware
and Installation or S7-400, M7-400
Programmable Controllers, Hardware and
Installation
or
4. Assign parameters to module Section 4.7
5. Connect measuring sensor or
loads to module
Sections 4.8 to 4.15
6. Commission configuration ”Commissioning” section in the Installation
Manual for the programmable controller being
used:
• S7-300 Programmable Controllers, Hardware
and Installation or S7-400, M7-400
Programmable Controllers, Hardware and
Installation
or
• ET 200M Distributed I/O Device
7. If commissioning was not
successful, diagnose
configuration
Section 4.16
