Siemens SIMATIC S7-300 Module data Reference Manual

Analog Modules
4-111
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Operational limit (in the entire temperature range, with
reference to the input range)
• Voltage input " 5
V " 10 V
1 to 5 V
0 to 10 V
" 0.6 %
" 50 mV
" 500 mV
"1 V
" 0.5 %
• Current input " 20 mA
0 to 20 mA
4 to 20 mA
" 0.5 %
• Resistors 0 to 6 kΩ
0 to 600 Ω
" 0.5 %
" 0.5 %
• Resistance
thermometer
Pt 100
Ni 100
Standard
" 1.2 K
Pt 100
Ni 100
Climate
" 1 K
Ni 1000, LG-Ni
1000 Standard
" 1 K
Ni 1000
LG-Ni 1000
Climate
" 1 K
Basic error (operational limit at 25 C, referred to input
range)
• Voltage input " 5
V " 10 V
1 to 5 V
0 to 10 V
" 0.4 %
" 50 mV
" 500 mV "1
V
" 0.3 %
• Current input " 20 mA
0 to 20 mA
4 to 20 mA
" 0.3 %
• Resistors 0 to 6 kΩ
0 to 600 Ω
" 0.3 %
" 0.3 %
• Resistance
thermometer
Pt 100
Ni 100
Standard
" 1 K
Pt 100
Ni 100
Climate
" 0.8 K
Ni 1000
LG-Ni 1000
Standard
" 0.8 K
Ni 1000 LG-Ni
1000
Climate
" 0.8 K
Temperature error (with
reference to the input
range)
" 0.006 %/K / 0.006 K/K
Linearity error (with
reference to the input
range)
" 0.1 % / 0.1 K
Repeat accuracy (in the
steady state at 25 C,
referred to the input range)
" 0.1 % / " 0.1 K
Status, interrupts, diagnostics
Interrupts None
Diagnostic functions None
Data for Selecting a Sensor
Input range (rated
values)/Input resistance
• Voltage " 50 mV
" 500 mV
"1 V
" 5 V
" 10 V
1 to 5 V;
0 to 10 V
100 kΩ
• Current " 20 mA
0 to 20 mA;
4 to 20 mA:
50 Ω
• Resistors 0 to 6 kΩ
0 to 600 Ω
100 MΩ
• Resistance
thermometer
Pt 100
Ni 100
Ni 1000
LG-Ni 1000
Standard /
Climate
100 MΩ
Maximum input voltage for
voltage input U+
(destruction limit)
max. 30 V continuous
Maximum input voltage for
voltage inputs M+, M-, S–
(destruction limit)
max. 12 V continuous;
30 V for max. 1 s
Maximum input current for
current input I+
(destruction limit)
40 mA

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
